Antenna information for STHCR3-G3 STHC

**Antenna Offsets**
SV System	Bands
GPS L1: N: -0.81 E: -0.16 U: 122.96 L2: N: -0.22 E: -0.15 U: 142.01 L5: N: -0.54 E: -0.44 U: 149.27 GLONASS L1: N: -0.66 E: -0.35 U: 123.03 L2: N: -0.70 E: -0.16 U: 144.26 GALILEO E1: N: -0.81 E: -0.16 U: 122.96 E5a: N: -0.54 E: -0.44 U: 149.27 E5b: N: -0.03 E: -0.20 U: 142.38 E5: N: -0.17 E: -0.29 U: 144.84 E6: N: -2.33 E: -0.35 U: 154.69 BeiDou E1: N: -0.81 E: -0.16 U: 122.96 E2: N: -0.89 E: -0.06 U: 122.77 E6: N: -1.72 E: -0.27 U: 150.65 QZSS L1: N: -0.81 E: -0.16 U: 122.96 L2: N: -0.22 E: -0.15 U: 142.01 L5: N: -0.54 E: -0.44 U: 149.27 IRNSS L5: N: -0.54 E: -0.44 U: 149.27 SBAS L1: N: -0.81 E: -0.16 U: 122.96 L5: N: -0.54 E: -0.44 U: 149.27	L1 GPS: N: -0.81 E: -0.16 U: 122.96 GLONASS: N: -0.66 E: -0.35 U: 123.03 QZSS: N: -0.81 E: -0.16 U: 122.96 SBAS: N: -0.81 E: -0.16 U: 122.96 L2 GPS: N: -0.22 E: -0.15 U: 142.01 GLONASS: N: -0.70 E: -0.16 U: 144.26 QZSS: N: -0.22 E: -0.15 U: 142.01 L5 GPS: N: -0.54 E: -0.44 U: 149.27 QZSS: N: -0.54 E: -0.44 U: 149.27 SBAS: N: -0.54 E: -0.44 U: 149.27 IRNSS: N: -0.54 E: -0.44 U: 149.27 E1 GALILEO: N: -0.81 E: -0.16 U: 122.96 BeiDou: N: -0.81 E: -0.16 U: 122.96 E2 BeiDou: N: -0.89 E: -0.06 U: 122.77 E5 GALILEO: N: -0.17 E: -0.29 U: 144.84 E5a GALILEO: N: -0.54 E: -0.44 U: 149.27 E5b GALILEO: N: -0.03 E: -0.20 U: 142.38 E6 GALILEO: N: -2.33 E: -0.35 U: 154.69 BeiDou: N: -1.72 E: -0.27 U: 150.65
